Electric Horizontal Self-Priming Pump For Gas Oil Kerosene

  • Electric Horizontal Self-Priming Pump For Gas Oil Kerosene
  • Electric Horizontal Self-Priming Pump For Gas Oil Kerosene
  • Electric Horizontal Self-Priming Pump For Gas Oil Kerosene
  • Electric Horizontal Self-Priming Pump For Gas Oil Kerosene

Electric Horizontal Self-Priming Pump For Gas Oil Kerosene

    Payment Type: L/C,T/T,Paypal,Western Union
    Terms of Trade: FOB,CFR,CIF,FCA
    Min. Order: 1 Piece/Pieces
    Delivery Time: 3 Days
    Packaging: wooden package
    Productivity: 1000 pcs/month
    Brand: Honghai
    Transportation: Ocean,Land,Air,express
    Place of Origin: China
    Supply Ability: 1000 pcs/month
    Certificate: ISO9001:2008
    HS Code: 8413709990
    Port: Xingang,Tianjin Sea Port,Shanghai Sea Port

Basic Info

Model No.: CYZ

Product Description

Electric Horizontal Self-priming Pump For Gas Oil Kerosene

Start and operation

1.Start the Centrifugal Pump, check turning of the shaft is correct or not.

2.when Seawater Centrifugal Pump rotation check noise and vibration.

3.Pay attention to the pressure gauge and vacuum meter reading, start after a period of time when the pressure gauge and vacuum gauge readings stabilized, shows that the pump has on the fluid, the pump into the normal working.

4.Before the pump nromal working, when it is in self-priming period, should pay special attention to oil pump in the condition of high temperature, if the process is too long, inside the pump oil temperature is too high, then stop the pump inspection.

5.If due to high temperature of the liquid in the pump self-priming difficulties, you can temporarily stop the pump, using pipeline liquid reflux or to add liquid to the pump liquid inject mouth , cooling the liquid in the pump, then start again.

6.Adjusting export valve, make the pressure gauge readings within the prescribed scope, avoid the lower limit of the prescribed scope of work, prevent caused by excessive shaft power motor overload, or make the pump produces gas turbid because of heavy traffic, affect the normal operation of pump, the pump strong vibration and noises.

7.Pump in the process of work if there is a strong vibration and noise, is likely to be caused by pump cavitation occurred, the causes of cavitation has two kinds: one is the inlet pipe flow is too big,second is the suction is too high.

When the velocity is too large should adjust the export control valve,elevated pressure gauge readings,when the inlet piping has blocked should be ruled out

in time;When high suction can decrease the pump mounting height.

8.Pump because of failure to stop the pump in the process of work, need at startup, export control valve should be slightly open (not all closed), both is advantageous to the self-priming process gas exhaust the export, and can ensure the pump starts under a lighter load.

9.Pay attention to check the pipeline system for leakage phenomenon.Note the power value of the machine.

10.Pump every 15 ~ 20 hours or every time before the use should check adding 10 machine oil at a time.



sea water pump


Pump's parameters sheet:

Model

Capacity

Head
m

NPSH

m

Speed
r/min

AP
kw

Motor

m3/h

L/min

Model

Power

kw

25CYZ-27

3

50

27

3-5

2900

0.6

YB90S-2

1.5

40CYZ-20

6.3

105

20

3-5

2900

0.88

YB802-2

1.1

40CYZ-40
(50CYZ-40)

10

167

40

3-5

2900

2.8

YB112M-2

4

50CYZ-12

15

250

12

3-5

2900

1.1

YB90S-2

1.5

50CYZ-20

18

300

20

3-5

2900

1.8

YB90L-2

2.2

50CYZ-35

14

233

35

3-5

2900

2.7

YB112M-2

4

50CYZ-50

12.5

208

50

3-5

2900

4.3

YB132S1-2

5.5

50CYZ-60

15

250

60

3-5

2900

6.3

YB132S2-2

7.5

50CYZ-75

20

333

75

3-5

2900

9.9

YB160M1-2

11

65CYZ-15

30

500

15

3-5

2900

1.92

YB100L-2

3

65CYZ-30

25

416

30

3-5

2900

3.2

YB112M-2

4

80CYZ-13

35

583

13

3-5

2900

1.9

YB100L-2

3

80CYZ-17

43

716

17

3-5

2900

3.1

YB112M-2

4

80CYZ-25

50

833

25

3-5

2900

5.2

YB132S2-2

7.5

80CYZ-55

60

1000

55

3-5

2900

15.0

YB160L-2

18.5

80CYZ-70

60

1000

70

3-5

2900

20.1

YB180M-2

22

100CYZ-40

100

1667

40

3-5

2900

18.3

YB180M-2

22

100CYZ-40A

100

1667

40

3-5

1470

18.5

YB180L-4

22

100CYZ-65

100

1667

65

3-5

2900

27.7

YB200L1-2

30

150CYZ-55

160

2667

55

3-5

2900

38.1

YB225M-2

45

150CYZ-65

170

2833

65

3-5

1470

51.0

YB250M-4

55

200CYZ-63

280

4667

63

3-5

1480

75.1

YB280M-4

90


Pump's pictures:

Self Priming Sea Water Pump

sea water pumpbilge water pumpmarine water pump
