River Dredge Pump Extracting Sand with Diesel Engine CE Approved
Product Description
We are professional manufacturer of Dredge pump extracting sand from river, which is designed specifically for heavy duty dredging in deep river .
1. Uses and Features:
.
The M.AH type slurry pumps have pump bodies (volute liners, front and back liners) that consist of replaceable wear-resistant metal liners or wear-resistant rubber liners, and impellers can also apply wear-resistant metal material or wear-resistant rubber material.The HH type slurry pumps only apply wear-resistant metal material as their pump bodies and impellers.
2. Performance:
Name: NP-WS Dredging Gravel Pump
Pump Type: Centrifugal
Drvie Type: DCZ
Power: Motor / Diesel
Discharge Size: 100-1000mm
Capacity: 180-25000(m³/h)
Head: 25-76(m)
MQQ: 1Set
3. Typical Applications:
The products are widely used in mining, power, metallurgy, coal, dreading, building material and other Industrial lines to pump concentrate, tailings, sludge and other abrasive, high density slurries.
Suction Hopper Dredging
Constructional Material
Sand gravel processing
Barge Loading
Sand Reclamation
1. Uses and Features:
.
The M.AH type slurry pumps have pump bodies (volute liners, front and back liners) that consist of replaceable wear-resistant metal liners or wear-resistant rubber liners, and impellers can also apply wear-resistant metal material or wear-resistant rubber material.The HH type slurry pumps only apply wear-resistant metal material as their pump bodies and impellers.
2. Performance:
Name: NP-WS Dredging Gravel Pump
Pump Type: Centrifugal
Drvie Type: DCZ
Power: Motor / Diesel
Discharge Size: 100-1000mm
Capacity: 180-25000(m³/h)
Head: 25-76(m)
MQQ: 1Set
3. Typical Applications:
The products are widely used in mining, power, metallurgy, coal, dreading, building material and other Industrial lines to pump concentrate, tailings, sludge and other abrasive, high density slurries.
Suction Hopper Dredging
Constructional Material
Sand gravel processing
Barge Loading
Sand Reclamation
| selection Chart and Performance | ||||
| model | max power(KW) | capacity(m3/H) | head(M) | speed |
| 40/25B-AH | 15 | 12.6-28.8 | 6-68 | 1200-3800 |
| 40/25C-HH | 30 | 16.2-34.2 | 25-92 | 1400-2200 |
| 50/40B-AH | 15 | 34.2-72 | 6-58 | 1200-3200 |
| 75/50C-AH | 30 | 39.6-86.4 | 12-64 | 1300-2700 |
| 75/50D-HH | 60 | 68.4-136.8 | 25-87 | 850-1400 |
| 100/75C-AH | 30 | 86.4-198 | 9-52 | 1000-2200 |
| 100/75E-HH | 120 | 126-252 | 12-97 | 600-1400 |
| 150/100D-AH | 60 | 162-360 | 12-56 | 800-1550 |
| 150/100S-HH | 560 | 324-720 | 30-118 | 600-1000 |
| 150S-HH | 560 | 468-1008 | 20-94 | 500-1000 |
| 200/150R-AH | 300 | 360-828 | 10-61 | 500-1140 |
| 250/200E-M | 120 | 666-1440 | 14-60 | 600-1100 |
| 250/200ST-AH | 560 | 612-1368 | 11-61 | 400-850 |
| 300/250ST-AH | 560 | 8936-1980 | 7-68 | 300-800 |
| 350/300ST-AH | 560 | 1260-2772 | 13-63 | 300-600 |
| 400/350TU-AH | 1200 | 1368-3060 | 11-63 | 250-550 |
| 500/450TU-AH | 1200 | 2520-5400 | 13-57 | 200-400 |
