UL Listed Fire Fighting Water Pump Comply with Nfpa20

Product Description

We are professional manufacturer for Diesel engine driven fire fighting pump equipment with high and stable quality, we manufacture the fire fighting pumps accoridng to NFPA20 standard , and we have made many Fire Pump solutions for many customers.

XBD/TPOW/TSWA/IS  Fire Fighting Pump

1. Inlet/OutletDN80-DN800
2. Impeller Diameter170mm-980mm
3. Rotary Speed730RPM-3500RPM
4. Flow Rates>11600m3/h
5. Head>200m
6. Power>2000KW
7. voltage 380V/400V/415V/440V/460V/525V etc.
8. frequency 50Hz/60HZ
9. working pressure >2.5Mpa
10. Materialcast iron, ductile iron, stainless steel, cast steel, aluminum, bronze,SS304,SS316,SS316L
11. Drive modeelectric motor and diesel engine
12. Diesel Cooling ModelWater cooled & air cooled
13. Method of Connectiondirect soft coupling connection, V-belt pulley connection,
14. Drive brand Cummins, Deutz, Ricardo, Perkins or Chinese Diesel Engine Weichai, SIEMENS Electric Motor
15. Skid Mounted on Trailer2 & 4 wheels Trailer
16. PackageStandard Exporting plywood case
for more detailed specification and performance data , please contact us directly by email or call.

1. Summarize
Development and production of the latest energy-efficient products. With high efficiency, low running noise, good anti-cavitation performance, reasonable structure, long service life, such as significant advantages. My factory production XBD series fire pump performance, technical requirements in line with the newly promulgated National GB6245-1998 "fire pump performance requirements and test methods" standards, products and optimize the use of computer design treatment, the company has the abundant technical force, rich production experience and perfect detection means, thus ensuring a stable and reliable product quality.
2. Usage

For non-delivery of water and solid particles of similar physical and chemical properties of liquid water use, mainly used for pressurized water fire fighting system, but also can be used in factories and mines to the drainage, water pressurized high-rise buildings, long-distance water, heating, bathroom, boilers, pressurized cold water, air-conditioning refrigeration systems and equipment supporting water and so on.

4. Main application:
Our fire pump is with Full seal, no leakage, corrosion resistance advantage, it is used in environmental protection, water treatment, fire protection etc. We are professional manufacturer fo fire fighting pump, we can also make fire pump packages with vertical jockey Water Pump, diesel engine auto controller, high discharge Multistage Pump.

specification and performance parameter
ModelCapacity( L/S)Pressure (Mpa)Power(KW)Rotary speed(rpm)
XBD1.6/5-5050.161.52950
XBD2.3/5-5050.2332950
XBD5/5-5050.55.52950
XBD7.3/5-5050.737.52950
XBD8.8/10-65100.8818.51480
XBD10.6/10-65101.06221480
XBD13.3/10-65101.33301480
XBD16/15-80151.6451480
XBD20.9/20-100X202.09751480
XBD22.1/25-W100252.211101480
XBD20.4/50-150502.041601480
XBD23.1/75-W200752.312801480

for more detailed specification and performance data , please contact us directly by email or call.
